Developer Guide

Whether you are building against Shio or contributing to it, start here.

Shio is an open-source, agent-native CMS. A coding agent builds and maintains the site; a curator approves what it produced; a headless delivery layer serves it. That order is the product, not a description of it — every capability lands on an agent-drivable surface first, and a feature reachable only from the console is considered incomplete.

The source lives at github.com/openviglet/shio and contributions are welcome.

---

The six surfaces

Before the stack, the shape. Every capability is exposed on a surface an agent can drive:

Surface	What it is
MCP server (POST /mcp)	Model Context Protocol tools — shio_context, shio_find, shio_read, shio_write, shio_apply, shio_publish, shio_assets, shio_changes, shio_verify, shio_digest, shio_remember. See MCP.
Agent gateway (/api/v2/agent/**)	A manifest, a context pack, planned batches, teaching errors, a review queue, diagnostics. See The agent surface.
Content as files (shio/content/**)	The whole site projected to front-mattered Markdown on disk, with a three-way merge back. See Content as files.
CLI (@viglet/shio)	pull, push, apply, publish, verify, clone, convert, types, dev, deploy, and more. See The shio CLI.
Content Delivery API (/api/v2/cda/**)	Stable REST + GraphQL reads, token-scoped, with TypeScript SDKs. See Content Delivery API.
React console	The curator's half: content browser, form widgets, Universal Editor, review queue, preview links. See The content console.

If you are adding a feature, the order to land it in is MCP → files/CLI → REST → console.

---

Tech Stack

Layer	Technology
Backend	Java 21 · Spring Boot 4.1.0
Database	H2 (dev) · PostgreSQL · MariaDB / MySQL · Oracle — schema owned by Liquibase
Cache	Hazelcast
Search	In the database by default. Viglet Turing indexing is optional and off by default — see Search & Caching.
Template Engine	Handlebars.java (no server-side script engine)
Frontend	React 19 · TypeScript · Radix UI · TailwindCSS · Vite
CLI / SDKs	Node · TypeScript, a pnpm workspace
Build	Maven (backend) · pnpm (JS workspace)
CI/CD	GitHub Actions

note

The versions in that table are checked against this repository's own build files by cli/conformance/docs-stack.conformance.mjs. A version that drifts fails a Shio build rather than misleading a reader here.

---

Setting up

Prerequisites

• Java 21 (Temurin recommended)
• Maven 3.9+ — or use the bundled ./mvnw
• Node 26+ and pnpm 11+
• Git
• Docker, only if you want to run the cross-database integration tests

Clone

git clone https://github.com/openviglet/shio.git
cd shio

Install the JS workspace

Once, at the repo root — it is a pnpm workspace covering the CLI, the SDKs and the console:

pnpm install

---

Running

Backend

./mvnw spring-boot:run -pl shio-app

The backend starts at http://localhost:2710 and serves the bundled console.

Console, with hot reload

pnpm --filter shio-react dev

Vite starts at http://localhost:5173 and proxies the API to the backend.

Production build

./mvnw clean package -pl shio-app

The JAR in shio-app/target/ bundles the backend and the compiled console assets.

---

Building and testing

The backend suite, which is the whole validation for most changes:

./mvnw -pl shio-app -am clean test -Dskip.npm=true

Two things about that line are not optional:

• clean. Without it, a call to a method that no longer exists can print "Nothing to compile" and BUILD SUCCESS, because an IDE's output in target/classes outlives the source it came from.
• -Dskip.npm=true for backend-only work, so the build does not rebuild the console.

The JS side:

pnpm test           # CLI, SDKs and console suites
pnpm conformance    # end-to-end checks against a running instance and the published docs

Integration tests are opt-in: add -DskipITs=false when your change touches multi-tenancy, the Liquibase schema, or CDA/static-file delivery. The two cross-database ITs are @Testcontainers(disabledWithoutDocker = true), so start Docker first — without it they skip, and a green run proves nothing about PostgreSQL or MariaDB.

---

Development URLs

Service	URL	Notes
Console	http://localhost:2710	Backend-served
Console dev server	http://localhost:5173	Vite hot-reload
Agent manifest	http://localhost:2710/api/v2/agent/manifest	One call describing the whole surface
MCP endpoint	http://localhost:2710/mcp	JSON-RPC 2.0 over streamable HTTP
GraphiQL	http://localhost:2710/graphiql	Interactive GraphQL
Delivered site	http://localhost:2710/sites/{site}/default/en/	Published pages

Default credentials

On first startup the login and password are admin/admin. Change the password immediately.

---

Project structure

shio/
├── shio-app/                # Spring Boot application
│   └── src/main/java/com/viglet/shio/
│       ├── api/             # REST controllers, incl. api/agent (the agent gateway + MCP)
│       ├── persistence/     # JPA entities and repositories
│       ├── render/          # Handlebars rendering engine
│       ├── webhook/         # Outbound webhooks
│       ├── exchange/        # Import/export
│       ├── provider/        # Auth and exchange providers
│       ├── graphql/         # GraphQL support
│       ├── turing/          # Optional Turing indexing
│       ├── schedule/        # Scheduled publish/unpublish sweep
│       ├── spring/          # Security configuration
│       └── onstartup/       # Seed data
│   └── src/main/resources/db/  # Liquibase changelogs — the schema's owner
├── shio-react/              # React console
├── cli/                     # The `shio` CLI and the conformance suites
├── sdk/                     # TypeScript delivery SDKs
├── shio-site/               # The public site
├── docs/                    # Internal roadmap, changelog and specs
├── k8s/ · containers/ · Dockerfile · docker-compose.yaml
└── pom.xml · pnpm-workspace.yaml

---

Deployment artefacts

Directory	File	Provided by
<SHIO_DIR>/	viglet-shio.jar	The Maven build
<SHIO_DIR>/	viglet-shio.properties	You (optional)

The optional properties file overrides database configuration and anything else in the Configuration Reference.

Spring Boot 4

JAR files are no longer directly executable. Launch with java -jar, and load external properties with --spring.config.additional-location — the .conf pattern used by older versions is gone.

---

The rules a contribution is judged by

These are binding, and a change that breaks one is wrong even if it was asked for:

1. Agent-first order — MCP → files/CLI → REST → console. A console-only feature is incomplete.
2. One call replaces a session — discovery is a feature: the manifest and context pack, not a docs problem.
3. Tokens are a measured budget — response budgets are asserted; a token regression fails the build.
4. Files beat APIs for authoring — Edit, Write and Grep are an agent's cheapest tools.
5. Determinism over cleverness — stable ordering, path addressing, idempotent writes, byte-identical serialization.
6. Errors are instructions — every 4xx carries fix / allowed / didYouMean / example.
7. Never surprise the curator — draft-default, dry runs, explicit publish, confirm tokens, attribution, a review queue.
8. Skipping steps needs appliable units — blueprints, not prose recipes.
9. Close the perception loop — cheap textual proof (lint, routes, render digest) instead of asking someone to look.
10. Compose, don't fork — MCP is a shape over the delivery API and console services, never a third contract.

Three things Shio deliberately does not do: host a model or run prompts, replace the Java backend, or add a parallel API semantic.

---

Code quality

Tool	Link
SonarCloud	sonarcloud.io/organizations/viglet
GitHub Actions	openviglet/shio/actions

---

Contributing

1. Fork openviglet/shio.
2. Branch: git checkout -b feature/my-improvement.
3. Run the suites — ./mvnw -pl shio-app -am clean test -Dskip.npm=true and pnpm test. A red suite blocks the change.
4. Commit with clear, descriptive messages.
5. Open a pull request describing what changed and why.

For larger contributions, open an issue first to discuss the approach.

tip

The open issues tagged good first issue or help wanted are the easiest place to start.

---
